50KG granule weighing packaging machine

DGS-50K
Electronic filling weighing and packaging. with high filling precision, it is suitable for the quantitative packaging of granule products such as snack food, candy, seeds, peanuts, salt, monosodium glutamate, grain, hardware and other granular products.
SHARE:
Features
1. All stainless steel structure
2. Independent suspension sensor, stable signal transmission, ensuring weighing accuracy
3. LCD touch screen, PLC control technology
4.The conveyor belt, sewing machine, can be matched/connected to use.
5. Weighing control system is designed according to the requirements of IP54 (dust and water proof).
Technical DATA
Filling range 5-50 kg
Packing speed 4-8 bags / min
Feeding method Pneumatic valve
Air pressure 0.6Mpa
Air consumption 1 cubic meter / hour
Power 380V / 1.1KW
Dimension(mm) (L)980×(W)850×(H)2620
Application
