Automatic bottle screw capping machine

AT-XG-ZXPD
It is suitable for automatic screw capping of various kinds of bottle products, medicines, veterinary drugs, food, cosmetics, hand soap, detergent, pesticides and lubricants. Adopts belt clip bottle positioning and automatic capping, wide applicability and easy adjustment.
SHARE:
Features
1.Suitable for plastic covers capping, such as screw caps, anti-theft caps, and child-proof caps.
2.With constant torque capping head, the pressure can be easily adjusted.
3.The structure is compact and reasonable, which is convenient to link with other equipment.
4.Horizontal design makes the assembly line convenient and aesthetic.
5.Adopts imported brand frequency converter, which can carry out stepless speed regulation.
6.With a strong electromagnetic left-handed torsion torque device , completely solves the problem that the traditional mechanical friction plate is sometimes tight and sometimes loose in the screw cap.
Technical DATA
Power AC220V / 50Hz,300W
Cap size 15~70mm, 40-100mm
Capping speed 40bottles/min
Bottle size 50~280mm(diameter), 260mm(height)
Air pressure 0.4~0.6MPa
Weight 150kg
Dimension 2000x470x1240mm
Application
