Automatic aluminum cap sealing machine

AT-SG
This machine is suitable for the metal, aluminum caps screwing and sealing which is controlled by inverter, bottle is positioned by the disc divider, the cap is automatically relocated and capped. Easy operation, stable and reliable, the capping head is easy to disassemble. Different caps can be used through easy adjustment.
and can be connected to the filling machine and labeling machine to integrate a production line.
SHARE:
Features
1.Disc divider positioning, without bottle or inaccurate positioning will automatically stop work.
2.Automatic cap organization and feeding by electromagnetic vibration.
3.The capping head is easy to disassemble and easy to change bottle types.
4.Panel-type operation, easier to adjust capping speed, etc.
5.International brands electrical components, A-class quality.
Technical DATA
Model AT-SG
Applicable bottle types Various round bottle caps
Bottle height 35 ~ 320mm
Cap diameter Φ12 ~ Φ35mm
Capping speed 0-50pcs/ min
Power 380v, 50 / 60HZ, 1.2KW
Machine dimension (mm) (L)1700×(W)700×(H)1600
Weight 300KG
Application
