Automatic screw capping machine

AT-DXG
Frequency converter control, the disc divider used for positioning the bottle, magnetic composite sheet structure, capping does not damage the cap, capping head is easy to disassemble, different caps and bottles only need to replace a few parts, can be integrate with filling machines and labeling machines.
It is mainly used for screw caps of various round plastic, aluminum and iron screw caps, and is suitable for screw caps of different bottle shapes in food, pharmaceutical, daily chemical, pesticide, cosmetics and other industries.
SHARE:
Features
1.Beautiful appearance, dexterity, fast capping speed.
2.Intelligent mechanical torque control, easy operation and adjustment.
3.Equipped with a constant torque capping head, the pressure can be easily adjusted;
4.The structure is compact and reasonable, and it can be easily integrate with other equipment into a production line.
Technical DATA
Number of capping heads 1 head
Working voltage AC220V,1KW
Cap size 15-50mm, 50-100mm
Bottle diameter Φ35-Φ130mm
Bottle height 50-320mm
Working speed 10~30 bottles/min
Dimensions 200*800*160cm
Weight 280kg
Application
