Y520

Features

1. Equipped with safety protection device, meets the requirements of enterprise safety management.
2. Intelligent temperature controller, accurate temperature control; to ensure the sealing is flat.
3. PLC servo system, pneumatic control system and large display touch screen; Maximize the filling precision, reliability and intelligence of the machine.
4. The whole packaging process of weighing, filling and bag making, date printing, inflation (exhaust) and finished product delivery, counting can be complete automatically.
5. Can be customized bag shape, like pillow-shaped bags, hanging hole bags etc.
6. Single belt transport film, fast and stable, small friction, less loss.
7. All stainless steel body and carbon steel spray body for selection.

Technical DATA

Model	AT-Y520
Production capacity	20-40bags / min
Measuring range	50-500ml，500-2000ml
Filling accuracy	1%
Bag size	(L) 80-400mm (W) 80-250mm
Air consumption	0.7Mpa 300L/min
power	2.5kw
Machine weight	600kg
Power supply voltage	220V50Hz
Packaging materials	OPP/CPP, CPP/PE and other thermal composite materials
Machine size	1795 1150 1650 mm

Application

Form fill and seal viscous packaging machine

Sachet powder packaging machine

Sachet granule packaging machine

4 head linear weighing packaging machine

Sachet liquid packaging machine

Vertical powder form fill and seal packaging machine

Vertical volumetric form fill and seal packaging machine for granule

Multihead weigher form fill and seal packaging machine

Vertical form fill and seal packaging machine
