Automatic aluminum foil sealing machine

AT-LB-YFK
The machine use roll-shaped foil film sealing. It will heat, seal and cut into shape automatically after the bottle is positioned.
SHARE:
Features
The machine use roll-shaped foil film sealing. It will heat, seal and cut into shape automatically after the bottle is positioned. Unmanned operation which improve the production efficiency.
Stainless steel structure, 7-inch touch screen man-machine interface. It can be integrated with the production line.
Compared with the traditional aluminum foil sealing machine, it will not be sealed by induction heating after the cap is screwed or retighten the caps.
Technical DATA
Production speed 20-30 bottles/min
Sealing diameter 30-100mm, square or rectangular.
Sealing material Plastic composite film, aluminum foil, PP, PE etc
Air pressure range 4-8KG/CM2
Temperature range 0-300 degrees
Voltage 220V/110V ,0.5/1Kw
Machine size 2500*1000*1500MM
Net weight 220KG
Application
